Unit - MCK – B/BR
NO PART DESCRIPTION NO. PART DESCRIPTION
1 DRAIN PUMP 11 HOLDER GRILLE SHORT
2 FAN MOTOR 12 DRAIN PAN
3 PLATE, WIRE 13 COIL HOLDER
4 HANGER BRACKET A 14 COIL ASSY
5 ASSY, VALVE PLATE BOTTOM 15 TURBO FAN
6 ASSY, VALVE PLATE TOP 16 ASSY PANEL A
7 ASSY PANEL B 17 BUSH, FAN MOTOR
8 HANGER BRACKET B 18 BASE PAN
9 CONTROL BOX ASSY 19 FLOAT SWITCH
10 HOLDER GRILLE LONG 20 DRAIN PUMP SUPPORT PLATE
93
