McQuay MCK 020A

Model : MCK010C/CR
MCK015C/CR
MCK020C/CR
NO. PART DESCRIPTION NO PART DESCRIPTION
1 ASSY. BASE 14 BUSH
,
DRAIN PUMP
2 ASSY. CASING 15 ASSY. DRAIN PUMP SUPPORT BUCKET
3 ASSY. COIL 16 ASSY.
,
ENDPLATE SUPPORT
4 COVER
,
FAN 17 CLIP
,
COIL SENSOR
(
6mm
)
5 BLOWER WHEEL
,
TURBO FAN FX330 TU YAMAHA 18 TUBE
,
COIL SENSOR
6 PLATE
,
WIRE 19 BRACKET
,
COIL
7 MOTOR
,
ACK20C-501 HONG LU 20 COVER
,
TERMINAL
8 BUSH
,
FAN MOTOR 21 COVER
,
WIRE
9 BUSH
,
FAN MOTOR RING 22 CONNECTOR
,
DRAIN CK
10 ASSY.
,
CONTROL BO
X
23 HOSE
,
DRAIN CK
11 DRAIN PUMP PJV-0732 24 ASSY.
,
COVER VALVE
12 LEVEL SWITCH/ FLOAT SWITCH FS-06122A 25 ASSY.
,
DRAIN PAN
13 BUSH
,
WIRE NRID22
X
OD 36xT10.0
–
MODEL CE/SB 26 BUSH
,
WIRE
