MCW-H
MODEL
WATER
FLOW
W.P.D
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
0.24
5.6 1882 1377 1765 1358 1668 1329 1542 1271 1358 1222
0.33 9.7 2124 1552 2018 1513 1882 1504 1746 1474 1610 1436
0.42
14.8 2299 1688 2144 1649 2018 1610 1882 1591 1736 1562
0.51 21.6 2425 1775 2202 1746 2124 1698 1969 1649 1824 1630
0.36 4 2823 2086 2648 2037 2435 1989 2231 1959 2183 1930
0.48 9.2 3133 2309 2929 2260 2735 2231 2522 2202 2444 2153
0.6 13.2 3376 2474 3143 2415 2929 2377 2697 2338 2600 2318
0.72
18.7 3550 2619 3317 2551 3075 2522 2832 2474 2735 2415
0.42
7.3 3541 2580 3308 2522 3104 2474 2862 2435 2493 2386
0.6 13.8 4064 2881 3822 2949 3579 2920 3308 2900 3036 2842
0.78 21.6 4443 3259 4258 3220 3861 3182 3599 3143 3308 3104
0.96 31 4705 3405 4394 3385 4103 3347 3783 3308 3482 3279
0.72
18.7 5675 4132 5316 4093 4947 4055 4530 3987 4142 3851
0.9 32.7 6121 4278 5713 4229 5296 4132 4918 4074 4511 3987
1.08 38.2 6470 4520 5975 4326 5607 4268 5170 4229 4753 4220
1.26
50 6761 4685 6295 4637 5849 4559 5393 4540 4937 4462
1.14 12.5 7547 5548 7081 5461 6538 5403 5878 5287 5364 5160
1.44 18.7 8158 5704 7663 5626 7149 5578 6615 5529 6033 5510
1.74 26.2 8652 6130 8090 6063 7518 6014 6984 5936 6421 5801
2.04
34.5 9040 6324 8449 6266 7857 6218 7275 6179 6703 6033
1.2
13.6 8352 5539 7799 6004 7188 6111 6615 5956 6092 5849
1.5 20.1 9002 6354 8449 6247 7838 6218 7236 6150 6577 6053
1.8 26.5 9555 6683 8914 6577 8264 6518 7663 6509 7013 6489
2.1
33.7 9991 6994 9322 6868 8652 6800 7964 6761 7324 6732
1.56 21.5 10389 7265 9710 7178 9002 7139 8235 7052 7508 6974
1.92 32.7
11136 8216 10379 7993 9671 7896 8895 7828 8129 7479
2.28
40.7 11747 8449 10951 8391 10146 8323 9322 8206 8555 7876
2.64
54.3 12222 8682 11398 8546 10563 8449 9719 8361 8866 8158
NOTES:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN
SPEED MUST MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
TOTAL:TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL
MEDIUM
TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.8 0.8 0.8 0.8
LOW
TOTAL 0.66 0.6 0.65 0.65 0.68 0.7 0.71
SENSIBLE 0.58 0.55 0.58 0.6 0.62 0.63 0.66
