15
MCW-F
MODEL
WATER
FLOW
W.P.D
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
0.24
0.51 2134 1562 2000 1500 1900 1400 1800 1400 1540 1300
0.33 0.96 2400 1700 2200 1600 2100 1584 1900 1596 1800 1495
0.42
1.56 2600 1849 2400 1700 2200 1696 2100 1722 1900 1626
0.51 2.29 2700 1944 2500 1800 2400 1788 2200 1785 2000 1697
0.36 2.19 3201 2365 3000 2250 2773 2095 2604 2159 2475 2053
0.48 3.89 3540 2529 3194 2390 3053 2350 2744 2384 2733 2242
0.6 6.08 3818 2709 3519 2490 3194 2504 3009 2531 2845 2414
0.72
8.76 3953 2869 3767 2630 3474 2657 3165 2678 3000 2515
0.42
3.08 4015 2926 3747 2786 3535 2606 3340 2682 2827 2538
0.6 6.29 4592 3156 4167 3118 3994 3076 3599 3140 3394 2959
0.78 10.6 5024 3570 4767 3320 4210 3352 4016 3402 3620 3232
0.96 16.1 5238 3729 4989 3490 4636 3526 4227 3581 3819 3414
0.72
10.04 6435 4686 6022 4521 5634 4272 5287 4392 4697 4096
0.9 15.69 6915 4686 6230 4472 5910 4353 5352 4410 5042 4151
1.08 22.59 7317 4951 6690 4460 6113 4496 5770 4578 5201 4394
1.26
30.75 7528 5132 7148 4780 6608 4803 6026 4914 5415 4646
1.14 5.53 8558 6292 8022 6032 7445 5692 6860 5824 6083 5489
1.44 8.83 9216 6248 8356 5949 7978 5876 7199 5985 6745 5737
1.74 12.89 9786 6715 9057 6250 8197 6336 7794 6426 7027 6040
2.04 17.72
10066 6928 9593 6460 8877 6550 8128 6689 7351 6282
1.2
6.44 9471 6281 8835 6632 8185 6438 7721 6562 6908 6221
1.5 10.1 10170 6959 9213 6605 8746 6550 7874 6657 7352 6302
1.8 14.49 10806 7321 9980 6780 9012 6867 8552 7046 7674 6757
2.1 19.72 11124
7661 10584 7080 9775 7164 8898 7319 8032 7009
1.56 11.21 11781 8239 11000 7929 10251 7521 9611 7769 8514 7418
1.92
16.98 12581 8999 11317 8451 10792 8318 9679 8474 9087 7787
2.28 23.94 13285 9254 12261
8650 11063 8768 10403 8883 9362 8201
2.64 32.1
13608 9509 12941 8810 11934 8901 10859 9051 9723 8494
NOTES:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN
SPEED MUST MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
TOTAL:TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL
MEDIUM
TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.8 0.8 0.8 0.8
LOW
TOTAL 0.66 0.6 0.65 0.65 0.68 0.7 0.71
SENSIBLE 0.58 0.55 0.58 0.6 0.62 0.63 0.66
