5
MCW-H
MODEL
AIR FLOW
HIGH
m
3
/h 360 510 750 1010 1380 1570 2000
CFM 212 300 441 594 812 924 1176
MEDIUM
m
3
/h 250 350 470 770 1070 1110 1470
CFM 147 206 276 453 629 653 865
LOW
m
3
/h 180 230 330 490 720 820 1010
CFM 106 135 194 288 424 482 594
EXTERNAL STATIC PRESSURE
Pa 0,30,60,80
in.wg 0,0.12,0.24,0.32
TOTAL COOLING CAPACITY
W 2130 3100 4260 5980 7580 8570 10380
Btu/h 7268 10578 14536 20405 25864 29242 35418
SENSIBLE COOLING CAPACITY
W 1683 2285 3146 4272 5862 6220 7531
Btu/h 5742 7798 10735 14578 20002 21224 25696
TOTAL HEATING CAPACITY
W 1350 2280 3210 4290 5120 6940 8490
Btu/h 4606 7780 10953 14638 17470 23680 28969
WATER FLOW RATE
m
3
/h 0.4 0.6 0.8 1.1 1.4 1.6 1.9
USGPM 1.8 2.5 3.4 4.8 6.1 6.9 8.5
WATER FLOW RATE
m
3
/h 0.2 0.2 0.2 0.2 0.2 0.5 0.5
USGPM 1.1 1.1 1.1 1.1 1.1 2.2 2.2
Pa 14.6 12.0 21.6 38.2 18.4 21.0 32.7
in.wg. 0.1 0.0 0.1 0.2 0.1 0.1 0.1
Pa 12.0 13.5 14.8 20.7 4.0 12.8 14.6
in.wg. 0.0 0.1 0.1 0.1 0.0 0.1 0.1
UNIT WEIGHT
kg 20.0 24.0 28.0 32.0 44.0 47.0 49.0
lb 44.1 52.9 61.7 70.5 97.0 103.6 108.0
UNIT GROSS WEIGHT
kg 22.7 26.8 31.5 35.6 47.0 50.8 54.2
lb 50.0 59.1 69.4 78.5 103.6 112.0 119.5
UNIT WEIGHT
kg 22.0 27.0 31.0 36.0 48.0 52.0 56.0
lb 48.5 59.5 68.3 79.4 105.8 114.6 123.5
UNIT GROSS WEIGHT
kg 24.7 29.8 34.5 39.6 51.0 55.8 61.2
lb 54.5 65.7 76.1 87.3 112.4 123.0 134.9
CONDENSATE DRAIN PIPE SIZE
R3/4
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL THE UNITS ARE BEING TESTED UNDER FOLLOWING CONTITION:
a) COOLING: 27°C DB/19.5°C WB INDOOR AND WATER INLET 7°C OUTLET 12°C
b) HEATING: 21°C DB INDOOR AND WATER 60°C INLET.WATER FLOW:SAME WITH COOLING CONDITION.
