MCW-F
MODEL
AIR FLOW
HIGH
m
3
/h 360 510 750 1010 1380 1570 2000
CFM 212 300 441 594 812 924 1176
MEDIUM
m
3
/h 250 350 470 770 1070 1110 1470
CFM 147 206 276 453 629 653 865
LOW
m
3
/h 180 230 330 490 720 820 1010
CFM 106 135 194 288 424 482 594
EXTERNAL STATIC PRESSURE
Pa 0,30,60,80
in.wg 0,0.12,0.24,0.32
TOTAL COOLING CAPACITY
W 2622 3418 5277 7185 8691 10261 12791
Btu/h 8948 11661 18007 24517 29653 35013 43644
SENSIBLE COOLING CAPACITY
W 1783 2406 3536 5047 6365 7297 9382
Btu/h 6085 8210 12066 17222 21719 24899 32011
TOTAL HEATING CAPACITY
W 4196 5468 8444 11496 13905 16418 20465
Btu/h 14317 18658 28811 39227 47445 56020 69830
WATER FLOW RATE
m
3
/h 0.5 0.6 0.9 1.3 1.5 1.8 2.3
USGPM 2.0 2.7 4.1 5.5 6.8 8.0 10.1
kPa 1.3 6.0 1.3 27.0 8.8 12.0 20.0
in.wg. 5.7 26.4 5.7 118.9 38.7 52.8 88.1
UNIT WEIGHT
kg 20.0 24.0 28.0 32.0 44.0 47.0 49.0
lb 44.1 52.9 61.7 70.5 97.0 103.6 108.0
UNIT GROSS WEIGHT
kg 22.7 26.8 31.5 35.6 47.0 50.8 54.2
lb 50.0 59.1 69.4 78.5 103.6 112.0 119.5
UNIT WEIGHT
kg 22.0 27.0 31.0 36.0 48.0 52.0 56.0
lb 48.5 59.5 68.3 79.4 105.8 114.6 123.5
UNIT GROSS WEIGHT
kg 24.7 29.8 34.5 39.6 51.0 55.8 61.2
lb 54.5 65.7 76.1 87.3 112.4 123.0 134.9
CONDENSATE DRAIN PIPE SIZE
R3/4
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL THE UNITS ARE BEING TESTED UNDER FOLLOWING CONTITION:
a) COOLING: 27°C DB/19.5°C WB INDOOR AND WATER INLET 7°C OUTLET 12°C
b) HEATING: 21°C DB INDOOR AND WATER 60°C INLET.WATER FLOW:SAME WITH COOLING CONDITION.
