McQuay MDB100B User Manual

10
Cooling only
NOTES :
1. ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94.
2. NOMINAL COOLING CAPACITIES ARE BASED ON THE FOLLOWING CONDITIONS. INDOOR 26.7 °CDB, 19.4 °CWB, OUTDOOR 35 °CDB.
3. ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY MANUFACTURER WITHOUT PRIOR NOTICE.
MODEL INDOOR UNIT
MDB450B3 MDB500B4 MDB600B4 MDB750B5
OUTDOOR UNIT
MMC100B x 4
MMC100C x 4
MMC150C x 3
MMC125B x 4
MMC150C x 4
MMC150C x 5
TOTAL OUTDOOR Btu/h
450,000 500,000 600,000 750,000
COOLING
35 °CDB
kcal/h
113,400
126,000
151,200
189,000
CAPACITY W
131,850 146,500 175,800 219,750
MATERIAL
CASING FINISHING
INSULATION
HEIGHT (H)
mm (in)
1,546 (60.86)
1,546 (60.86)
1,977 (77.83)
2,257 (88.85)
DIMENSION WIDTH (W) mm (in)
2,274 (89.52) 2,274 (89.52) 2,274 (89.52) 2,274 (89.52)
DEPTH (D)
mm (in)
1,466 (57.71)
1,466 (57.71)
1,905 (75.00)
1,905 (75.00)
NET WEIGHT
kg (lb)
339 (747)
350 (771)
999 (2,202)
1,084 (2,389)
NOISE LEVEL (SOUND POWER) dBA
93 96 89 93
EVAPORATOR COIL
TYPE
MATERIAL
TUBE WALL THICKNESS mm (in)
OUTER DIAMETER mm (in)
MATERIAL
FIN THICKNESS mm (in)
ROWS
4
5
6
6
FIN PER INCH
14
12
12
12
CAPACITY STEP
%
100-67-33-0
100-75-50-25-0
100-75-50-25-0
100-80-60-40-20-0
FACE AREA
m
2
(ft
2
)
2.58 (27.78)
2.55 (27.45)
3.37 (36.32)
3.97 (42.73)
FACE VELOCITY m/min (FPM)
147.82 (485) 166.42 (546) 150.87 (495) 160.32 (526)
EVAPORATOR BLOWER
TYPE / DRIVE
BLOWER MATERIAL
BLOWER DIAMETER mm (in)
591.82 (23.30) 591.82 (23.30) 785.00 (30.90) 785.00 (30.90)
BLOWER LENGTH
mm (in)
563.88 (22.20)
563.88 (22.20)
706.00 (27.79)
706.00 (27.79)
AIR FLOW CMM (CFM)
382.43 (13,500) 424.92 (15,000) 509.91 (18,000) 637.39 (22,500)
EXTERNAL STATIC PRESSURE
mm wg (in wg)
25.40 (1.00)
25.40 (1.00)
30.48 (1.20)
35.56 (1.40)
BLOWER PULLEY DIAMETER mm
2 SPA 250
2 SPA 315
3 SPA 400
3 SPA 400
MOTOR PULLEY DIAMETER mm
2 SPA 112 2 SPA 150 3 SPA 132 3 SPA 140
PULLEY TYPE
B3
B3
B3
B3
EVAPORATOR BLOWER MOTOR
TYPE
POWER SUPPLY V / Ph / Hz
NUMBER x RATED RUNNING CURRENT A
14.40 20.70 20.70 28.10
NUMBER x RATED OUTPUT W
7,500
11,000
11,000
15,000
NUMBER x RATED INPUT W
6,302 8,035 9,200 11,683
MOTOR POLES
4
4
4
4
REFRIGERANT
TYPE
TYPE OF GAS PRECHARGED
CONTROL
PIPE CONNECTION
PIPE SIZE LIQUID mm (in)
15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8)
GAS
mm (in)
34.92 (1-3/8)
31.75 (1-1/4)
34.92 (1-3/8)
34.92 (1-3/8)
DRAIN PIPE CONNECTION mm (in)
AIR FILTER
TYPE
SIZE LENGTH x HEIGHT mm
668 x 661 668 x 661 668 x 579 668 x 672
DEPTH
mm (in)
50.8 (2.00)
50.8 (2.00)
50.8 (2.00)
50.8 (2.00)
QUANTITY
6 6 9 9
MDB400B4
INDOOR UNIT
591.82 (23.30)
563.88 (22.20)
339.94 (12,000)
20.32 (0.80)
2 SPA 250
2 SPA 106
B3
668 x 661
50.8 (2.00)
400 / 3 / 50
10.90
4,835
6
5,500
4
NITROGEN HOLDING
WASHABLE VILEDON
THERMOSTAT EXPANSION VALVE
BRAZING
15.88 (5/8)
28.58 (1-1/8)
400,000
100,800
ZINC COATED STEEL
330 (727)
90
1,466 (57.71)
R22
25.40 (1.00)
SQUIRREL CAGE INDUCTION
1,546 (60.86)
2,274 (89.52)
CROSS FINNED TUBES
SEAMLESS COPPER
0.35 (0.013)
9.52 (3/8)
ALUMINIUM
ELECTRO GALVANIZED MILD STEEL
EPOXY POLYESTER POWDER COATING
FIBREGLASS / PE
117,200
0.127 (0.005)
14
CENTRIFUGAL / BELT DRIVEN
100-75-50-25-0
2.38 (25.62)
142.94 (468)
4
CASING
MATERIAL
FINISHING
HEIGHT (H)
mm (in)
946 (37.24)
971.4 (38.24)
1,041 (40.98)
946 (37.24)
1,041 (40.98)
1,041 (40.98)
DIMENSION WIDTH (W) mm (in)
1,116 (43.93)
1,393 (54.84)
1,116 (43.93)
1,116 (43.93)
1,116 (43.93)
1,116 (43.93)
DEPTH (D) mm (in)
939 (36.96) 500 (19.68) 939 (36.96) 939 (36.96) 939 (36.96) 939 (36.96)
NET WEIGHT kg (lb)
193 (425)
176 (387)
258 (568)
224 (493)
258 (568)
258 (568)
NOISE LEVEL (SOUND POWER) dBA
72 75 77 75 77 77
CONDENSER COIL
TYPE
MATERIAL
TUBE WALL THICKNESS mm (in)
OUTER DIAMETER mm (in)
MATERIAL
FIN THICKNESS mm (in)
NUMBER x ROWS
2 x 2
1 x 3
2 x 2
2 x 2
2 x 2
2 x 2
FIN PER INCH
12 14 14 16 14 14
FACE AREA
m
2
(ft
2
)
1.76 (19.00)
1.35 (14.54)
1.24 (13.38)
1.76 (19.00)
1.24 (13.38)
1.24 (13.38)
FACE VELOCITY m/min (FPM)
112.16 (368)
146.60 (481)
131.97 (433)
112.16 (368)
131.97 (433)
131.97 (433)
CONDENSER FAN
DRIVE
TYPE
P. SPLIT CAPACITOR P. SPLIT CAPACITOR
INDUCTION INDUCTION
BLADE MATERIAL
BLADE DIAMETER mm (in)
660.40 (26) 762.00 (30) 762.00 (30) 660.40 (26) 762.00 (30) 762.00 (30)
POWER SUPPLY V / Ph / Hz
380-415/3/50
380-415/3/50
380-415/3/50
380-415/3/50
380-415/3/50
380-415/3/50
NUMBER x RATED RUNNING CURRENT A
1.50 3.35 4.35 1.43 4.35 4.35
NUMBER x RATED INPUT
W
660
1,110
3,200
640
3,200
3,200
MOTOR POLES
6 8 6 6 6 6
AIR FLOW
CMM (CFM)
198.30 (7,000)
198.30 (7,000)
328.61 (11,600)
198.30 (7,000)
328.61 (11,600)
328.61 (11,600)
COMPRESSOR
TYPE
POWER SUPPLY V / Ph / Hz
RATED RUNNING CURRENT
A
16.9
16.9
23.5
17.9
23.5
23.5
RATED INPUT W
9,040
9,040
13,300
10,200
13,300
13,300
MAXIMUM STARTING CURRENT A
125.0 125.0 198.0 110.0 198.0 198.0
PROTECTION DEVICE
STAGE OF CAPACITY CONTROL
STARTER TYPE
REFRIGERANT
TYPE
TYPE OF GAS PRECHARGED
OUTDOOR
NITROGEN HOLDING
AUTO-TRANSFORMER
R22
380-415/3/50
ON / OFF
9.52 (3/8)
ALUMINIUM
0.127 (0.005)
OVERLOAD PROTECTION AND AUTO RESET HIGH / LOW PRESSURE SWITCH
PROPELLER / DIRECT
SCROLL
ALUMINIUM
INDUCTION
CROSS FINNED TUBES
SEAMLESS COPPER
0.35 (0.013)
ELECTRO GALVANIZED MILD STEEL
EPOXY POLYESTER POWDER
