NOTES :
1. ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94.
2. NOMINAL COOLING CAPACITIES ARE BASED ON THE FOLLOWING CONDITIONS. INDOOR 26.7 °CDB, 19.4 °CWB, OUTDOOR 35 °CDB.
3. ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY MANUFACTURER WITHOUT PRIOR NOTICE.
MODEL INDOOR UNIT MDB075BR MDB100BR MDB125CR MDB150BR2 MDB200BR2
OUTDOOR UNIT MMC075CR MMC100BR MMC125BR MMC075CR X2 MMC100BR X2
NORMINAL Btu/h 74000 98800 116000 148000 197600
COOLING kcal/h 18650 24899 29234 37298 49798
CAPACITY W 21688 28957 33998 43376 57913
TOTAL Btu/h
74000 96560 120000 148000 193000
HEATING kcal/h
18650 24333 30242 37298 48635
CAPACITY W 21688 28300 35170 43376 56565
NOMINAL TOTAL POWER (COOLING) W 8500 10219 12168 16970 21424
NOMINAL TOTAL POWER (HEATING) W 9100 9477 10496 18170 19940
NOMINAL TOTAL CURRENT (COOLING) A 14.2 18.6 22.9 29.0 39.5
NOMINAL TOTAL CURRENT (HEATING) A 14.5 17.9 21.0 29.6 38.1
MATERIAL
CASING FINISHING
INSULATION
HEIGHT (H)
mm (in)
572 (22.51)
572 (22.51)
736 (28.97)
885 (34.84)
945 (37.20)
DIMENSION WIDTH (W) mm (in) 1502 (59.13) 1502 (59.13)
1640 (64.56)
1640 (64.54) 1894 (74.56)
DEPTH (D)
mm (in)
761 (29.96)
761 (29.96)
965 (37.99)
1040 (40.94)
980 (38.58)
NET WEIGHT
kg (lb)
92 (202)
102 (224)
171 (376)
189 (416)
220 (485)
NOISE LEVEL (SOUND POWER) dBA 66 71 78 79 85
EVAPORATOR COIL
TYPE
MATERIAL INNER GROOVE
TUBE WALL THICKNESS mm (in) 0.36 (0.014)
OUTER DIAMETER mm (in)
MATERIAL
THICKNESS mm (in)
ROWS 3 4 4 4 4
FIN PER INCH
12
12
12
12
12
CAPACITY STEP %
100-0 100-0 100-0 100-50-0 100-50-0
FACE AREA
m
2
(ft
2
)
0.54 (5.82) 0.54 (5.82) 0.79 (8.60) 1.00 (10.82) 1.20 (12.92)
FACE VELOCITY m/min (FPM) 130.75 (429) 167.64 (550) 148.73 (488) 129.54 (425) 150.87 (495)
EVAPORATOR BLOWER
TYPE / DRIVE
BLOWER MATERIAL
QUANTITY
2 2 1 1 1
BLOWER DIAMETER mm (in)
BLOWER LENGTH mm (in)
AIR FLOW L/s (CFM) 1180 (2500) 1322 (2800) 1982 (4200) 2171 (4600) 3021 (6400)
EXTERNAL STATIC PRESSURE (DRY COIL) mm wg (in wg) 15 (0.6) 10 (0.4) 20 (0.8) 15 (0.6) 15 (0.6)
BLOWER PULLEY DIAMETER mm - - 160 160 140
MOTOR PULLEY DIAMETER mm - - 85 80 80
PULLEY TYPE - - 1SPZ 1SPZ 2SPZ
V-BELT TYPE - - SPZ1060 SPZ1060 SPZ1010
EVAPORATOR BLOWER MOTOR
TYPE
POWER SUPPLY V / Ph / Hz
NUMBER x RATED RUNNING CURRENT A 2 x 1.85 2 x 2.00 2.7 3.1 5.0
NUMBER x MOTOR OUTPUT W 2 x 270 2 x 332 1500 1500 3000
NUMBER x RATED INPUT W 2 x 415 2 x 436 1100 1630 2730
MOTOR POLES 6 6 4 4 4
REFRIGERANT
TYPE
TYPE OF GAS PRECHARGED
PIPE CONNECTION
PIPE SIZE LIQUID mm (in) 12.70 (1/2) 15.88 (5/8) 15.88 (5/8) 12.70 (1/2) 15.88 (5/8)
GAS mm (in)
25.40 (1.00) 28.58 (1-1/8) 34.92 (1-3/8) 25.40 (1.00) 28.58 (1-1/8)
DRAIN PIPE CONNECTION mm (in)
AIR FILTER
TYPE
SIZE LENGTH x HEIGHT mm 622 x 433 622 x 433 457 x 589 457 x 589 542 x 738
DEPTH mm (in) 12.70 (1/2) 12.70 (1/2) 50.8 (2.00) 50.8 (2.00) 50.8 (2.00)
QUANTITY 2 2 3 3 3
FIN
WASHABLE SARAN NET WASHABLE VILEDON
R22
NITROGEN HOLDING
BRAZING
25.40 (1.00)
PERMANENT SPLIT CAPACITOR
SQUIRREL CAGE INDUCTION
220 - 240 / 1 / 50 400 / 3 / 50
ZINC COATED STEEL
282.70 (11.13) 394.97 (15.55)
203.00 (8.00) 381.00 (15.00)
ALUMINIUM
0.127 (0.005)
CENTRIFUGAL / DIRECT CENTRIFUGAL / BELT DRIVEN
INDOOR UNIT
ELECTRO GALVANIZED MILD STEEL
EPOXY POLYESTER POWDER COATING
PE
CROSS FINNED TUBES
SEAMLESS PLAIN COPPER SEAMLESS PLAIN COPPER
0.35 (0.013) 0.35 (0.013)
9.52 (3/8)
CASING MATERIAL
FINISHING
HEIGHT (H)
mm (in)
946 (37.24) 946 (37.24) 946 (37.24) 946 (37.24) 946 (37.24)
DIMENSION WIDTH (W) mm (in) 1300 (51.18) 1116 (43.93) 1116 (43.93) 1300 (51.18) 1116 (43.93)
DEPTH (D) mm (in) 500 (19.68) 939 (36.96) 939 (36.96) 500 (19.68) 939 (36.96)
NET WEIGHT kg (lb) 145 (319) 164 (361) 169 (372) 145 (319) 164 (361)
NOISE LEVEL (SOUND POWER) dBA
70 72 75 70 72
CONDENSER COIL
TYPE
MATERIAL INNER GROOVE
TUBE WALL THICKNESS mm (in) 0.36 (0.014)
OUTER DIAMETER mm (in)
MATERIAL
FIN THICKNESS mm (in)
NUMBER x ROWS
1 x 2 2 x 2 2 x 2 1 x 2 2 x 2
FIN PER INCH
14 12 18 14 12
FACE AREA
m
2
(ft
2
)
1.23 (13.25) 1.76 (19.00) 1.76 (19.00) 1.23 (13.25) 1.76 (19.00)
FACE VELOCITY m/min (FPM) 138.07 (453) 112.16 (368) 144.38 (474) 138.07 (453) 112.16 (368)
CONDENSER FAN
TYPE / DRIVE
BLADE MATERIAL
QUANTITY 1 1 1 1 1
BLADE DIAMETER mm (in) 660.40 (26) 660.40 (26) 762.00 (30) 660.40 (26) 660.40 (26)
POWER SUPPLY V / Ph / Hz 380-415 / 3 / 50 220-240 / 1 / 50 220-240 / 1 / 50
NUMBER x RATED RUNNING CURRENT A 1 x 3.8 1 x 3.8 3.2 3.8 3.8
NUMBER x MOTOR OUTPUT W 1 x 480 1 x 480 1250 480 480
NUMBER x RATED INPUT W 1 x 740 1 x 740 1660 740 740
MOTOR POLES 6 6 6 6 6
AIR FLOW CMM (CFM) 169.97 (6000) 169.97 (6000) 254.84 (9000) 169.97 (6000) 169.97 (6000)
COMPRESSOR
TYPE
POWER SUPPLY V / Ph / Hz
RATED RUNNING CURRENT (COOLING) A 11.7 16.0 17.0 11.7 16.0
RATED RUNNING CURRENT (HEATING) A 12.0 15.3 15.1 12.0 15.3
RATED INPUT (COOLING) W 6930 8607 9408 6930 8607
RATED INPUT (HEATING) W 7530 7865 7736 7530 7865
MAXIMUM STARTING CURRENT A
95 125 110 95 125
PROTECTION DEVICE
STAGE OF CAPACITY CONTROL
REFRIGERANT
TYPE
CONTROL
0.35 (0.013)
OUTDOOR BIFLOW TXV
ALUMINIUM
OVERLOAD PROTECTION & AUTO RESET HIGH PRESSURE SWITCH
ON / OFF
R22
OUTDOOR UNIT
ELECTRO GALVANIZED MILD STEEL
EPOXY POLYESTER POWDER
CROSS FINNED TUBES
SEAMLESS BARE COPPER SEAMLESS BARE COPPER
0.35 (0.013)
220 - 240 / 1 / 50
SCROLL
380-415/3/50
9.52 (3/8)
ALUMINIUM
0.127 (0.005)
PROPELLER / DIRECT
