12
Heatpump
NOTES :
1. ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94.
2. NOMINAL COOLING CAPACITIES ARE BASED ON THE FOLLOWING CONDITIONS. INDOOR 26.7 °CDB, 19.4 °CWB, OUTDOOR 35 °CDB.
3. ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY MANUFACTURER WITHOUT PRIOR NOTICE.
MODEL INDOOR UNIT MDB250BR2 MDB300BR3 MDB400BR4 MDB500BR4
OUTDOOR UNIT MMC125BR x 2 MMC100BR x 3 MMC100BR x 1 MMC125BR x 2 MMC100BR x 4 MMC125BR x 4
NORMINAL Btu/h 232000 296400 395200 464000
COOLING kcal/h 58468 74698 99597 116935
CAPACITY W 67995 86870 115826 135991
TOTAL Btu/h 240000 289500 386000 480000
HEATING kcal/h
60484 72953 97270 120968
CAPACITY W 70340 84848 113130 140680
NOMINAL TOTAL POWER (COOLING) W 25506 32041 42223 52307
NOMINAL TOTAL POWER (HEATING) W 22162 29815 39255 45619
NOMINAL TOTAL CURRENT (COOLING) A 46.7 58.9 77.8 95.5
NOMINAL TOTAL CURRENT (HEATING) A 42.9 56.8 75.0 87.9
MATERIAL
CASING FINISHING
INSULATION
HEIGHT (H)
mm (in)
1291 (50.82)
1291 (50.82)
1546 (60.86)
1546 (60.86)
DIMENSION WIDTH (W) mm (in) 1866 (73.46) 1866 (73.46) 2274 (89.52)
2274 (89.52)
DEPTH (D)
mm (in)
1199 (47.20)
1199 (47.20)
1466 (57.71)
1466 (57.71)
NET WEIGHT
kg (lb)
343 (756)
346 (762)
513 (1130)
606 (1335)
NOISE LEVEL (SOUND POWER) dBA 87 89 90 96
EVAPORATOR COIL
TYPE
MATERIAL
TUBE WALL THICKNESS mm (in)
OUTER DIAMETER mm (in)
MATERIAL
FIN THICKNESS mm (in)
ROWS 4 5 4 5
FIN PER INCH
14
12
14
12
CAPACITY STEP % 100-50-0 100-67-33-0 100-75-50-25-0 100-75-50-25-0
FACE AREA
m
2
(ft
2
)
1.48 (16.01) 1.62 (17.50) 2.38 (25.62) 2.55 (27.45)
FACE VELOCITY m/min (FPM) 152.40 (500) 156.66 (514) 142.94 (468) 166.42 (546)
EVAPORATOR BLOWER
TYPE / DRIVE
BLOWER MATERIAL
BLOWER DIAMETER mm (in) 469.90 (18.50) 469.90 (18.50) 591.82 (23.30) 591.8 (23.30)
BLOWER LENGTH mm (in) 459.99 (18.11) 459.99 (18.11) 563.88 (22.20) 563.88 (22.20)
AIR FLOW L/s (CFM) 3776 (8000) 4248 (9000) 5664 (12000) 7080 (15000)
EXTERNAL STATIC PRESSURE mm wg (in wg) 35 (1.4) 35 (1.4) 35 (1.4) 40 (1.6)
BLOWER PULLEY DIAMETER mm 180 180 250 315
MOTOR PULLEY DIAMETER mm 90 95 106 150
PULLEY TYPE 2SPZ 2SPZ 2SPA 2SPA
V-BELT TYPE SPZ1700 SPZ1700 SPA2160 SPA2270
EVAPORATOR BLOWER MOTOR
TYPE
POWER SUPPLY V / Ph / Hz
RATED RUNNING CURRENT A 6.3 7.1 8.7 14.7
MOTOR OUTPUT W 4000 4000 5500 11000
RATED INPUT W 3370 4000 4835 8035
MOTOR POLES 4 4 4 4
REFRIGERANT
TYPE
TYPE OF GAS PRECHARGED
PIPE CONNECTION
PIPE SIZE LIQUID mm (in) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8)
GAS mm (in)
34.92 (1-3/8) 28.58 (1-1/8) 28.58 (1-1/8) 34.92 (1-3/8) 28.58 (1-1/8) 34.92 (1-3/8)
DRAIN PIPE CONNECTION mm (in)
AIR FILTER
TYPE
SIZE LENGTH x HEIGHT mm 533 x 532 533 x 532 668 x 661 668 x 661
DEPTH mm (in) 50.8 (2.00) 50.8 (2.00) 50.8 (2.00) 50.8 (2.00)
QUANTITY 6 6 6 6
6
WASHABLE VILEDON
617 x 661
50.8 (2.00)
4
R22
NITROGEN HOLDING
BRAZING
400 / 3 / 50
8.4
5500
4510
125
2SPZ
SPZ2360
SQUIRREL CAGE INDUCTION
459.99 (18.11)
4956 (10500)
35 (1.4)
250
124.96 (410)
CENTRIFUGAL / BELT DRIVEN
ZINC COATED STEEL
469.90 (18.50)
4
12
100-67-33-0
2.38 (25.62)
0.35 (0.013)
9.52 (3/8)
ALUMINIUM
0.127 (0.005)
440 (970)
92
CROSS FINNED TUBES
SEAMLESS COPPER
31907
66.1
61.6
INDOOR UNIT
ELECTRO GALVANIZED MILD STEEL
EPOXY POLYESTER POWDER COATING
PE / FIBER GLASS
1546 (60.86)
2122 (83.54)
1199 (47.20)
336500
84797
98623
35993
MDB350BR3
330800
83367
96952
CASING MATERIAL
FINISHING
HEIGHT (H)
mm (in)
946 (37.24) 946 (37.24) 946 (37.24) 946 (37.24) 946 (37.24) 946 (37.24)
DIMENSION WIDTH (W) mm (in) 1116 (43.93) 1116 (43.93) 1116 (43.93) 1116 (43.93) 1116 (43.93) 1116 (43.93)
DEPTH (D) mm (in) 939 (36.96) 939 (36.96) 939 (36.96) 939 (36.96) 939 (36.96) 939 (36.96)
NET WEIGHT kg (lb) 169 (372) 164 (361) 164 (361) 169 (372) 164 (361) 169 (372)
NOISE LEVEL (SOUND POWER) dBA
75 72 72 75 72 75
CONDENSER COIL
TYPE
MATERIAL INNER GROOVE INNER GROOVE BARE TUBE INNER GROOVE
TUBE WALL THICKNESS mm (in) 0.36 (0.014) 0.36 (0.014) 0.35 (0.013) 0.36 (0.014)
OUTER DIAMETER mm (in)
MATERIAL
FIN THICKNESS mm (in)
NUMBER x ROWS
2 x 2 2 x 2 2 x 2 2 x 2 2 x 2 2 x 2
FIN PER INCH
18 12 12 18 12 18
FACE AREA
m
2
(ft
2
)
1.76 (19.00) 1.76 (19.00) 1.76 (19.00) 1.76 (19.00) 1.76 (19.00) 1.76 (19.00)
FACE VELOCITY m/min (FPM) 144.38 (474) 112.16 (368) 112.16 (368) 144.38 (474) 112.16 (368) 144.38 (474)
CONDENSER FAN
TYPE / DRIVE
BLADE MATERIAL
QUANTITY 1 1 1 1 1 1
BLADE DIAMETER mm (in) 762.0 (30) 660.40 (26) 660.40 (26) 762.00 (30) 660.40 (26) 762.00 (30)
POWER SUPPLY V / Ph / Hz 380-415 / 3 / 50 220-240 / 1 / 50 220-240 / 1 / 50 380-415 / 3 / 50 220-240 / 1 / 50 380-415 / 3 / 50
RATED RUNNING CURRENT A 3.2 3.8 3.8 3.2 3.8 3.2
MOTOR OUTPUT W 1250 480 480 1250 480 1250
RATED INPUT POWER W 1660 740 740 1660 740 1660
MOTOR POLES 6 6 6 6 6 6
AIR FLOW CMM (CFM) 254.84 (9000) 169.97 (6000) 169.97 (6000) 254.84 (9000) 169.97 (6000) 254.84 (9000)
COMPRESSOR
TYPE
POWER SUPPLY V / Ph / Hz
RATED RUNNING CURRENT (COOLING) A 17.0 16.0 16.0 17.0 16.0 17.0
RATED RUNNING CURRENT (HEATING) A 15.1 15.3 15.3 15.1 15.3 15.1
RATED INPUT (COOLING) W 9408 8607 8607 9408 8607 9408
RATED INPUT (HEATING) W 7736 7865 7865 7736 7865 7736
MAXIMUM STARTING CURRENT A
110 125 125 110 125 110
PROTECTION DEVICE
STAGE OF CAPACITY CONTROL
REFRIGERANT
TYPE
CONTROL
OUTDOOR UNIT
ELECTRO GALVANIZED MILD STEEL
EPOXY POLYESTER POWDER
CROSS FINNED TUBES
BARE TUBE
0.35 (0.014)
9.52 (3/8)
ALUMINIUM
0.127 (0.005)
PROPELLER / DIRECT
ALUMINIUM
SCROLL
380-415/3/50
OVERLOAD PROTECTION AND AUTO RESET HIGH PRESSURE SWITCH
ON / OFF
R22
OUTDOOR BIFLOW TXV
