Design & installation Guide For McQuay MDS Multi System
1.6 Performance Parameter
1.6.1 Ceiling concealed
Model
Indoor MCC MCC MCC MCC MCC MCC MCC MCC MCC MCC
unit
008T 010T 015T 018T 020T 025T 030T 040T 050T 060T
Cooling
W
2000 2500 3650 4500 5600 6500 7800 10600 12400 14400
capacity
Heating
W
2200 2600 3700 4700 6100 7400 8900 11600 14500 17300
capacity
Nominal input W 47 47 81 82 82 123 158 276 276 280
Power supply 220V～/50Hz
Air
High m
3
/h 450 450 580 800 800 960 1200 1900 1900 2100
flow Medium m
3
/h 370 370 470 650 650 780 950 1520 1520 1750
Low m
3
/h 280 280 380 540 540 600 800 1300 1300 1460
ESP Pa 15(0/30/50) 30(15/50/70) 50(15/30/70)
Dimension mm 1030x469x220 1290x490x250 1640x490x250 1900x490x250
Weight kg 22 22 22 25 25 27 28 39 39 45
Sound(High/
dB (A) 31/29/27 31/29/27 34/32/30 35/32/29 35/32/29 37/36/35 42/40/38 47/45/43 47/45/43 48/46/44
medium/Low)
Piping
Liquid pipe Φ mm(in) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 9.52 (3/8) 9.52 (3/8) 9.52(3/8) 9.52(3/8) 9.52(3/8) 9.52(3/8) 9.52(3/8)
size
Gas pipe Φ mm(in) 9.52 (3/8) 9.52 (3/8) 12.7 (1/2) 15.88(5/8) 15.88(5/8) 15.88(5/8) 15.88(5/8) 19.05(3/4) 19.05(3/4) 19.05(3/4)
Drainage pipe inch R3/4
Capacity range
0.8HP 1.0HP 1.5HP 1.8HP 2.0HP 2.5HP 3.0HP 4.0HP 5.0HP 6.0HP
MCC ● ● ● ● ● ● ● ● ● ●
MCK ● ● ● ● ● ● ● ●
MCM ● ● ●
MDB ● ●
Model
1.5.2 Indoor products
Notes:
◆ The nominal cooling cap acity is gotten in the return air temperature of 27℃ /19℃ , and the ambient temperature of 35℃ /24℃ .
◆ The nominal heating capacity is gotten in the return air temperature of 20 ℃/15℃ , and the ambient temperature of 7℃ /6℃ .
◆ The sound level is gotten from the test room, it may differ in actual use due to the ambient temperature or other causes.
◆ The above parameters are of heat pump parameters.
Notes:
◆ The nominal cooling cap acity is gotten in the return air temperature of 27℃ /19℃ , and the ambient temperature of 35℃ /24℃ .
◆ The nominal heating capacit y is gotten in the return air temperature of 20℃ /15℃ , and the ambient temperature of 7℃ /6℃ .
◆ The sound level is gotten from the test room, it may differ in actual use due to the ambient temperature or other causes.
1.6.2 High static pressure duct unit
Model Indoor unit Indoor unit MDB050T MDB060T
Nominal cooling capacity W 12500 14000
Nominal heating capacity W 14000 16500
Nominal input W 615 789
Power supply 220V～/50Hz
Air flow(High/Medium/Low) m
3
/h 2550/2040/1650 3000/2540/1920
ESP Pa 100 100
Dimension mm 1230 × 910 × 350 1430 ×910 ×350
Weight kg 69 75
Sound Level(High/Medium/Low) dB(A) 58/55/52 60/56/53
Liquid pipe outside diameter Φ mm(in) 9.52(3/8) 9.52(3/8)
pipe size Gas pipe outside diameterΦ mm(in) 19.05(3/4) 19.05(3/4)
Drainage pipe inch R3/4
