McQuay MDS030A Design & Installation Guide

-93-
Design & installation Guide For McQuay MDS Multi System
Water boiling point(c) pressure(mmHg) vacuity(mmHg)
40 55 -705
30 36 -724
26.7 25 -735
24.4 23 -737
22.2 20 -740
20.6 18 -742
17.8 15 -745
15.0 13 -747
11.7 10 -750
7.2 8 -752
0 5 -755
● Selection of vacuum pump
When selecting a vacuum pump, please pay attention to the follows:
◆ The range of vacuum pump must be up to -755mmHg
◆ The vacuum pump should have a large air flow (more than 40 litres/min).
