Before installing the air conditioner unit, please read the following safety precautions carefully.
SAFETY PRECAUTIONS
! Warning
• Installation and maintenance should be performed by qualified persons who are familiar with local code and
regulation, and experienced with this type of appliance.
• All field wiring must be installed in accordance with the national wiring regulation.
• Ensure that the rated voltage of the unit corresponds to that of the name plate before commencing wiring work
according to the wiring diagram.
• The unit must be GROUNDED to prevent possible hazard due to insulation failure.
• All electrical wiring must not touch the refrigerant piping, compressor and any moving parts of the fan motors.
• Confirm that the unit has been switched OFF before installing or servicing the unit.
IMPORTANT
DO NOT INSTALL OR USE THE AIR CONDITIONER UNIT IN A LAUNDRY ROOM.
CONTENTS
! Caution
Please take note on the following important points when installing.
• Do not install the unit where leakage of flammable gas may occur.
If gas leaks and accumulates at the surrounding of the unit, it may cause fire ignition.
• Ensure that the drainage piping is connected properly.
If the drainage piping is not connected properly, it may cause water leakage which will dampen the
furniture.
• Do not overcharge the unit.
This unit is factory pre-charged. Overcharge will cause over-current or damage to the compressor.
• Ensure that the unit panel is covered back after service or installation.
Unsecured panel will cause unit to operate noisily.
- Safety Precautions page 2
- Installation Diagram page 3
- Outline and Dimensions page 3
- Installation Of The Indoor Unit page 5
- Installation Of The Outdoor Unit page 6
- Refrigerant Piping page 7
- Electrical Connection page 8
- Purging The Refrigerant Piping page 12
- Additional Charge page 13
- Overall Checking page 14
- Standard Operating Condition page 14
- Auto Random Re-Start Function page 15
- Service And Maintenance page 15
- Trouble Shooting page 16
CCC-0700 (01~16) ENG* 2/1/01, 10:41 AM2
