Water pump
1
7.3
Underlay for water pump support
3
7.4
Water switch
1
8
Wind wheel clasp
1
9
Centrifugal fan
1
10
Fan motor for indoor unit
1
11
Rear brattice
1
12
Chassis assy
1
13
Auxiliary fixing board for evaporator
2
14
Front brattice
1
15
Hanger
4
16
Discharge pipe joint
1
17
Side maintenance board for water pump
1
18
Valve panel
1
1.8. The Specification of Wiring
Model
Indoor power wire
/Diameter (mm
2
)
Indoor-Outdor Signal wire
/Diameter (mm
2
)
Outdoor power wire
/Diameter (mm
2
)
36K
3*1.0
≥0.75
3*4.0
60K
3*1.0
≥0.75
3*6.0
Note: Outdoor and indoor units supply separately.
1.9. Field Wiring
