McQuay SWP 095 User Manual

10 IM708
Physical Data
Table 3: Compressor circuit charge
*Charge quantities listed are average. Actual charge quantity is dependent on
individual unit evaporator coil circuiting. Actual charge quantities are stamped
on each unit nameplate.
Table 2: SWP 018 Through SWP 105
Data
SWP Model Size
018 023 028 035 040 045 055 065 070 080 095 105
Compressor
Quantity 2, 3, 4 3, 4 4 4 4 4 4 4 4 4 4, 6 6
Size See Unit Data Plate
Evaporator Coil
Face Area (Ft.
2
)
11.8 15.3 17.7 23.3 27.7 30.7 36.1 41.5 46.3 51.1 55.9 63.2
Rows 4, 6 4, 6 4, 6 4, 6 4, 6 4, 6 6 6 6 6 6 6
Fpi 12 12 12 12 12 12 12 12 12 12 12 12
Waterside Economizer Coil
Face Area (Ft.
2
)
11.8 15.3 17.7 23.3 27.7 30.7 36.1 41.5 46.3 51.1 55.9 63.2
Rows 4444 4 4 4 4 4 4 4 4
Fpi 12 12 12 12 12 12 12 12 12 12 12 12
Maximum Working Pressure
(psig)
400 400 400 400 400 400 400 400 400 400 400 400
Hot Water Heating Coil
Face Area (Ft.
2
)
9.3 12.8 15.2 20.2 24.5 26.8 30.4 35.8 39.9 44.4 48.3 51.9
Rows 1, 2 1, 2 1, 2 1, 2 1, 2 1, 2 1, 2 1, 2 1, 2 1 1 1
Fpi 12 12 12 12 12 12 12 12 12 12 12 12
Electric Heat
Kw 34 34 34 34 34 68 68 68 68 68 68 68
Filters
(Quantity) Size 4” Depth
(6)20x20x4
(2)25x20x4
(6)20x20x4
(2)25x20x4
(6)20x20x4
(2)25x20x4
(10)25x20x4 (10)25x20x4 (12)25x20x4 (12)25x20x4 (18) 20x20x4 (6)16x20x4
(12)25x20x4
(3)20x20x4
(15)25x20x4
(6)16x20x4
(15)25x20x4
(4)16x20x4
(17)20x25x4
(1)16x25x4
Evaporator Fan
a
a. Standard fan TSP limit is 5.5 inch of water. Consult your local McQuay sales representative for applications beyond this range.
Quantity 1111 1 1 1 1 1 1 1 1
Size 15 18 18 20 20 22 25 25 25 27 27 33
Minimum Horsepower 5 7.5 10 10 15 15 20 20 20 25 30 40
Maximum Horsepower 10 15 20 20 25 30 40 40 40 50 60 60
Minimum Design cfm, CV 2950 3825 4425 5825 6925 7675 9025 10375 11575 12775 13975 15800
Minimum Design cfm, VAV 4720 6120 7080 9320 11080 12280 14440 16600 18520 20440 22360 25280
Maximum Design cfm 7080 9180 10620 13980 16620 18420 21660 24900 27780 30660 33540 37920
Condenser
Quantity 2, 3, 4 3, 4 4 4 4 4 4 4 4 4 4, 6 6
Waterside Working Pressure
(psig)
400 400 400 400 400 400 400 400 400 400 400 400
Minimum Entering
Temperature (F)
55° 55° 55° 55° 55° 55° 55° 55 55° 55° 55° 55°
Minimum GPM 25 41 53 66 69 94 105 105 121 134 138 180
Maximum GPM 88 108 125 159 166 215 237 237 251 349 358 493
COMPRESSOR
(HP)
*REFRIGERANT
CHARGE PER
CIRCUIT (R-22)
OIL CHARGE
PER CIRCUIT
(OZ.)
69 lbs.66
10 14 lbs. 112
13 18 lbs. 128
15 22 lbs. 256
20 27 lbs. 256
