McQuay SWP 095 User Manual

12 IM708
Figure 13. Unit Front Plan
Figure 14. Front Elevation
Note: Service connections determined when facing the front of the
unit. Left-hand standard, right-hand optional. Please indicate on
the unit submittal.
Note: Unit sizes 018, 023 and 028 have a single mechanical access
panel in bottom front and bottom back.
Figure 15. Back Elevation
Figure 16. Left Side
Figure 17. Discharge Plenum (Optional)
Table 5. Discharge Plenum
Left Side
Piping Connections
(See Notes)
(Optional)
Right Side
Piping Connections
(See Notes)
Supply
Fan Motor
Return Air
A23
Disconnect
Switch (Optional)
MicroTech II Panel
ASD (Optional)
Electrical
Access
Mechanical
Access
D
B
72"
Power Entry
7/8" Pilot K.O.
M
2.0”
2.0” Typical
H H
F
29”
D
B
K x L
Return Air Opening
Mechanical
Access
(See Notes)
(Optional)
Multi-Directional
Plenum
(See Notes, Page 11)
1” Neoprene
Isolation Pads,
Shipped Separately
Unit Size Length (in.) Depth (in.) Height (in.)
018D-028D 84 72 29
035D-040D 100 72 29
045D-065D 120 81 29
070D 132 81 29
080D 144 84 29
095D-105D 156 84 29
Lifting Lug
1” Typ.
A/2
38.5”
(N) Water In
(N) Water Out
1-1/8” ODS Drain
K x L Return Air
(Optional)
Multi-Directional
Plenum
(See Notes, Page 11)
A
44.5”
(P) Hot Water In
(P) Hot Water Out
Plan View
Left/Right Elevation
Front/Back Elevation
A27
Length
Depth
29”
H
A
B
H
29”
3”
2” Min
3”
2” Min
