McQuay WSHP User Manual

OUTLINE AND DIMENSIONS
MODEL SELECTION
08A01 CKA APLWS2 BOARD LAYOUT
Fan Coil Unit: 5CKWS20/25/30/40/50AR
(With wireless remote control & with wired remote control)
Model Selection Table
System Jumper Position
1 SINGLE WSHP (Default)
2 TANDEM
3DX
12 3
12 3
12 3
Model A B C D E F G H I J K
20AR
820 820 363 335 28 930 930 642 622 555 555
25AR
(32,2) (32,2) (14,3) (13,2) (1,1) (36,6) (36,6) (25,2) (24,5) (21,9) (21,9)
30AR
40AR
50AR
B
A
C
D
E
F
H
K
J
I
G
All dimensions are in mm/(in)
N2
N1
LIVE
WTP
LOW
MED HIGH
OF/COMP2
4WV
HOT KEEP
MODEL
123
CAL
CN5
ROOM
ID
OD
COMP.
L
TRANSFORMER
REFER TO TABLE
A5
CN6 CN2
