33-MAINTENANCE AND CLEANING
Technical Dept. - All rights reserved - Reproduction prohibited
CHECKING THE INTERNAL COMPONENTS
ATTENTION!
The internal electromechanical components must only be checked by qualied personnel whose technical expertise
includes combustion and electricity.
We recommend that an annual maintenance service is carried out (with a scheduled service contract). This service is essentially a visual
and functional inspection of the internal components. The following is a summary of the checks and/or maintenance that are essential
for the correct operation of the product.
PARTS/INTERVAL 1 DAY 23 DAYS 1 YEAR
UNDER THE USER'S
RESPONSIBILITY
Brazier
Ash pan
Glass
BY THE QUALIFIED
TECHNICIAN
Heat exchanger
Smoke duct
Gaskets
Door closure operation
REPLACING GASKETS AFTER 1 SEASON OF OPERATION
• SMOKE CAP GASKET
• DOOR SEAL GASKET D.10
• DOOR SEAL GASKET D.5
• SMOKE FAN GASKET
AND FOR THE SLIDE VERSION
• SMOKE BOX SILICONE GASKET
