INSERT
BOXTHERM 70 AIR 9 BASIC M1
BOXTHERM 70 AIR 9 SLIDE M1
BOXTHERM 60 AIR 6 BASIC M1
BOXTHERM 60 AIR 6 SLIDE M1
PART 2 - OPERATION AND CLEANING
INSTALLATION GUIDE
EN
Instructions in English

Questions and Answers

  • P
    paulmcculloughAug 14, 2025
    What to do if my MCZ Stove does not switch on?
    • W
      William ParkerAug 14, 2025
      If your MCZ Stove isn't switching on, first ensure it's properly plugged in and the main switch is in the 'I/ON' position. Next, check the fuse and replace it with an identical one (5x20 mm T 3.15A) if tripped. Also, inspect and clean the brazier, ensuring it's correctly positioned. Check if the spark plug heats up and replace it if necessary. Finally, clear any blockages from the smoke outlet or duct, and if the spark plug is faulty, replace it.
  • D
    Douglas RobinsonAug 17, 2025
    Why do pellets accumulate in the brazier and the glass of the door gets dirty on my MCZ Stove?
    • A
      Andrew HarmonAug 17, 2025
      If pellets accumulate in the brazier of your MCZ Stove, the door glass gets dirty, and the flame is weak, it may be due to insufficient combustion air. Ensure the air inlet in the room is clear. Clean the brazier, making sure all holes are clear. Also, perform a general cleaning of the combustion chamber and smoke duct, and check the condition of the door gaskets. Another cause might be damp or unsuitable pellets, so consider changing the type of pellets you are using. Finally, a faulty smoke extractor motor could be the culprit, so check the motor and replace it if necessary.
  • N
    nashchristineAug 20, 2025
    Why does my MCZ Stove always run at maximum power when in automatic mode?
    • J
      Jerry RodriguezAug 21, 2025
      If your MCZ Stove is running at maximum power in automatic mode, first reset the temperature on the remote control, as the room thermostat might be in the maximum position. If that doesn't solve the issue, check the temperature probe and replace it if necessary. Lastly, the control panel may be faulty or malfunctioning, so inspect and replace it if needed.
  • A
    Alyssa BrownAug 25, 2025
    What to do if my MCZ Stove fire goes out or the boiler stops automatically?
    • O
      obowenAug 25, 2025
      If your MCZ Stove stops automatically or the fire goes out, start by filling the pellet hopper if it's empty. If the pellets aren't feeding, refer to the previous anomaly for solutions. Check if the pellet temperature safety probe has been triggered; if so, let the product cool, restore the thermostat, and switch it back on. If the issue continues, contact Technical Assistance. Ensure the timer setting isn't active. Make sure the door is properly closed, and replace worn gaskets with original ones. Change to pellets recommended by the manufacturer if the current ones are unsuitable. Check the fuel flow and clean the combustion chamber and smoke duct following the manual's instructions. Lastly, inspect and replace the smoke extraction motor if necessary.
  • D
    Daniel SanchezAug 27, 2025
    What to do if my MCZ Stove works for a few minutes and then switches off?
    • S
      Sandra SchmidtAug 27, 2025
      If your MCZ Stove works for a few minutes and then switches off, try repeating the start-up process, as the initial start-up phase may not have completed successfully. If there was a temporary power cut, switch the stove back on. Check for and clean any clogs in the smoke duct. Lastly, inspect and replace any faulty or malfunctioning temperature probes.
  • S
    seanthomasAug 31, 2025
    How to fix pellets not feeding into the combustion chamber in my MCZ Stove?
    • N
      Nicole PatrickAug 31, 2025
      If the pellets are not feeding into the combustion chamber of your MCZ Stove, begin by filling the pellet hopper if it's empty. If sawdust has blocked the feed screw, empty the hopper and manually remove the sawdust. If these steps don't resolve the issue, the gear motor or circuit board may be faulty and require replacement.
  • C
    Charles LynchSep 3, 2025
    Why is the smoke extractor motor not working on my MCZ Stove?
    • A
      Amanda MunozSep 3, 2025
      If the smoke extractor motor on your MCZ Stove isn't working, first check the mains voltage and the protection fuse to ensure there's electrical supply. If the supply is fine, inspect the motor and capacitor, replacing them if necessary. A defective circuit board or a broken control panel could also be the cause, requiring replacement.
  • T
    Tammy ButlerSep 6, 2025
    What to do if the remote control does not work for my MCZ Stove?
    • L
      Lorraine JohnsonSep 6, 2025
      If the remote control for your MCZ Stove isn't working, try replacing the battery first. If that doesn't solve the problem, the remote control itself may be faulty and need to be replaced.
  • E
    Elizabeth GravesSep 9, 2025
    Why does the convection air fan never stop on my MCZ Stove?
    • S
      Steven McmillanSep 9, 2025
      If the convection air fan in your MCZ Stove never stops, the thermal probe might be defective or faulty, requiring inspection and replacement if necessary. The fan itself could also be faulty; wait a few minutes and check its operation, replacing it if needed. Alternatively, the product might not have reached the shutdown temperature yet, so simply wait.

Summary

First Start-Up

General Precautions and Warnings

Essential safety measures and precautions before the initial ignition of the stove.

First App Start-Up and Association with MCZ Stoves

Wi-Fi Connection Methods (Home;Remote)

Explanation of Home Wi-Fi and Remote Wi-Fi connection methods for the app.

Automatic and Manual Connection Modes

Guidance on automatic and manual modes for connecting the app to the stove.

Stove Accessory Configuration

Emergency Panel

Panel Overview and Key Functions

Description of the emergency panel's LED indicators and button functions.

Manual Configuration

Safety Devices and Alarms

Safety Device Descriptions

Overview of the product's integrated safety devices.

Alarm Alerts and Troubleshooting Steps

Description of alarm alerts and initial troubleshooting steps.

Specific Alarms and Exit Procedures

Detailed information on specific alarms and procedures to exit alarm conditions.

Recommendations for Safe Use

Installation, Maintenance, and Safe Operation Guidelines

Essential guidelines for correct installation, maintenance, and safe operation.

Maintenance and Cleaning

Troubleshooting

Common Anomalies and Solutions

Identifies common stove anomalies and provides solutions for them.

Advanced Anomalies and Solutions

Addresses more complex anomalies related to operation and motor functions.

Power and Control Issues Troubleshooting

Troubleshooting issues related to power supply, controls, and fan operation.

MCZ BOXTHERM 70 AIR 9 BASIC M1 Specifications

General IconGeneral
BrandMCZ
ModelBOXTHERM 70 AIR 9 BASIC M1
CategoryIndoor Fireplace
LanguageEnglish
