3. Programming a microcontroller
Check the device ,code checksum
and device-options
Press the Enter-button.
* Press the Joy-button to read. This mode does not
update the E-PGM+ with the user-hex data.
For displaying the checksum and option-value.
Write
Read
The PC(personal computer) is not needed any more after completing the update.
Warning
Programmers supplie VDD with the target board.
* Do not turn on a user target board.
* Programmers can be damaged when the power of the target B/D is on.
