4
2.2 Outdoor Unit
Dimension
Mode
W(mm)
D(mm)
W1(mm)
A(mm)
B(mm)
MFS2i-24ARN1
845
335
918
560
335
Dimension
Mode
W(mm)
D(mm)
W1(mm)
A(mm)
B(mm)
MFS2i-48ARN1
990
355
1075
623
366
