5)Press to add number 1, press to reduce number 1, press to turn the
digit into right and press to turn the digit into left, press once done. If the
parameters setting is in the valid setting range,then it can be saved, if not, it can
not be saved.
6)Press and to save the parameters and exit from edition page.
7)Press to revert back to last class if in any setting position.
Revert back to default: put password “97011” when coming into parameters
setting, then all the parameters can be set as defaults.
Note: the data can’t be saved if the user didn’t press OK and STOP to confirm
the setting.
 Parameter setting
1)Basic setting
No
Parameter
Range (default)
Notes
0
Language
0-English
1- 简体中文
2-繁体中文
3-Русский
4-Espanol
5-Türk dili
Language option.
1
Gens poles
2/4/6/8(4)
When the flywheel teeth is set as 0,the
RPM will be resulted by frequency.
Pole 2: 50Hz---3000RPM.Pole 4: 50Hz--
-1500RPM.
Pole 6: 50Hz---1000RPM.Pole 8: 50Hz--
-750RPM
2
Gens AC system
Disable
1 phase 2 wire
2 phase 3 wire
3 phase 3 wire
3 phase 4 wire
Gens phases:
No gens parameters can be displayed if
setting as disable, which is applied to
water pump genset.
3
CT rate
5-6000A/5A(500A/5A)
Used for setting genset CT primary
current, secondary rated current 5A.
4
Rated frequency
40.0-80.0Hz(50.0Hz)
Setting generator rated frequency to
calculate the alarm value.
5
Rated phase
voltage
80-360V(230V)
Setting generator phase voltage to
calculate the alarm value.
6
Rated phase
current
5-6000A(500A)
Setting generator phase current to
calculate the alarm value.
7
Rated total
power
5-2000Kw(276Kw)
Set total power of generator to calculate
the average loading rate and alarm
value.
8
Rated battery
voltage
8.0-36.0V(24.0V)
Calculate the alarm value.
9
Rated RPM
500-4500RPM(1500)
Calculate the alarm value.
10
Flywheel teeth
0-300(0)
If the setting is 0, (RPM sensor
Disabled), then RPM is resulted by Hz.
