DC5xD MK3 GENSET CONTROLLER USER MANUAL
28
level alarm" switch is enabled, the engine low coolant level switch alarm is reported.
"ALARM" lights will light up, Generator stops running, displays "Low water level" on
the current fault screen.
Louver opening exception alarm
When the controller detects that the AUX. INPUT "Louver status input" switch is
active, it starts alarm delay and lasts for Normal alarm delay. When the "Louver
status input" switch is enabled, the Louver status input alarm is reported. "ALARM"
lights will light up, Generator stops running, displays "Louver abnormal" on the
current fault screen.
Emergency stop alarm
When the controller detects that the input voltage of PIN 3 is less than 2V, then start
alarm delay and the duration (Emergency delay) have not returned to normal, the
alarm of Emergency Stop is reported. "ALARM" lights will light up, Generator stops
running, and displays "Emergency stop" on the current fault screen.
Stop failure with frequency alarm
When the controller detects that the frequency is not "0" after the execution of the
shutdown, the alarm of stop failure is reported. "ALARM" lights will light up and
displays "Stop fail-Hz" on the current fault screen.
Stop failure with pressure alarm
When the controller detects that the Oil Pressure is not "0" after the execution of the
shutdown, the alarm of stop failure is reported. "ALARM" lights will light up and
displays " Stop fail-OP-A " on the current fault screen.
Stop failure with oil pressure switch
When the controller detects that the oil pressure switch has not returned after the
stop, it will alarm, the public alarm light “ALARM” lights will light up, and the current
fault screen displays “ Stop fail-OP-D”.
11. Parameters setting
Enter the edition page
Please set the parameters according to below steps:
1)The setting mode can be actived after pressing and simultaneously，
under the status of standby without any alarm. The default password is “07623”.
2)Press and add number 1, press to reduce number 1, press to turn
the digit into right, press to turn the digit into left, press once done. Then
system comes into menu after confirmation of password setting. The screen will
display error if password is wrong. The correct password should be put after
pressing any button.
3)Press to turn the digit into upper position, press to turn the digit into
lower position, press to get into parameters setting page.
4)Press to shift up the parameters, press to shift down the parameters,
press to get into parameter changing page.
To Next Page
