March 2017
Page C-23
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Platform Extension Lock Assembly
ITEM PART NO. QTY DESCRIPTION
-- 41140 1 Platform Extension Lock Assembly
1 50049 2 Nut M10
2 50002 2 Washer 10
3 41143 1 Foot Pedal
4 41144 1 Lock Pin Housing
5 41145 1 Spring
6 41146 1 Lock pin
7 41147 1 Bracket
8 50020 1 Bolt M10×50
