Mec 69 Series Service & Parts Manual

Page 4 XX69RT Series - Service & Parts Manual
November 2022Section 3 - Specications
3369RT Specications
Height, Working Maximum 38 ft 10 in 12 m
Height, Platform Maximum 32 ft 10 in 10 m
Height, Stowed Maximum
Rails Up
8 ft 6 in 2.59 m
Height, Stowed Maximum
Rails Folded
5 ft 11 in 1.82 m
Width, Standard Tires 5 ft 9 in 1.76 m
Length, Platform Retracted
Models Without Outriggers
10 ft 6 in 3.19 m
Length, Platform Retracted
Models With Outriggers
12 ft 7 in 3.84 m
Length, Platform Extended
Models Without Outriggers
14 ft 9 in 4.51 m
Length, Platform Extended
Models With Outriggers
15 ft 9 in 4.81 m
Platform Dimensions
Platform Length × Width
9 ft 5 in × 4 ft 11 in 2.88 × 1.52 m
Platform Extension Length 4 ft 8 in 1.43 m
Maximum Load Capacity 1,000 lb 454 kg
Maximum Wind Speed 28 mph 12.5 m/s
Wheelbase 7 ft 6 in 2.29 m
Turning Radius (Outside) 15 ft 1 in 4.60 m
Turning Radius (Inside) 6 ft 11 in 2.11 m
Ground Clearance 9
1
⁄
2
in 24 cm
Weight See Serial Label (Machine weights vary with option congurations)
Controls Proportional
AC Outlet In Platform Standard
Maximum Hydraulic Pressure (Functions) 3,500 psi 240 bar
Tire Size - Standard Tires 26 × 12-16.5
Airborne Noise Emissions
<80 dB
Maximum sound level at normal operating workstations (A-weighted)
Gradeability 40%
Maximum Working Slope X-1.5°, Y-3°
Drive Speeds
Stowed, Maximum 3.2 mph 5.0 km/h
Platform Raised, Maximum 0.3 mph 0.45 km/h
Floor Loading Information
Tire Load, Maximum 4,254 lb 1,930 kg
Outrigger Load, Maximum 4,254 lb 1,930 kg
Tire Contact Pressure 137 psi 945.5 kPa
Outrigger Contact Pressure 87 psi 602 kPa
Occupied Floor Pressure 178 psf 8.5 kPa
Note:Floor loading information is approximate and does not incorporate di󰀨erent option
congurations. It should be used only with adequate safety factors.
3369RT Specications
