MECA EVO 1 Setup Guide | Pedal set assembly MECA EVO 1 Setup Guide | Pedal set assembly
2) Mount brake pedal and electronics box as s e m b ly
Mount the brake pedal, slave cylinder* and electronic box assembly onto the baseplate
3) Mount clutch & throttle pedals
Mount clutch and throttle pedal onto the baseplate
*only for hydraulic brake pedal option
4x M6X12 screw
2x M6X12 screw
1x M6X18 screw
1x Steel washer
1x Plastic washer
