1. FEATURES
The Model “MPS” has been designed to guarantee the control of diaphragm valves mounted on pulse jet
dust collector filters containing filter bags or cartridges.
MPS main features include:
– Operates in MANUAL or AUTOMATIC mode
– Automatic start up of cleaning cycle according to set ∆P
– SHUT DOWN CLEANING with selectable number of cleaning cycles
– PRECOATING function for new filters or filters equipped with new filtering elements
– REMOTE function
– ALARM contact enabling connection to external alarms
– HOUR COUNTER
– ∆P value playback (option)
2. TECHNICAL CHARACTERISTICS
ENCLOSURE ABS grey – transparent cover
PROTECTION RATING IP65
DIMENSIONS MPS 4 / 8 / 12 / 16 outlets: box 163 × 185 × 113 mm
WEIGHT Approx. 2 kg circa for all models
CONNECTIONS Terminal blocks – max.section 2.5 mm²
TEMPERATURE
Storage: -20°C/+80°C.
Operation: -10°C/+50°C, with duty cycle 30%.
CODE INPUT OUTPUT
P1
230 V (±20%) − 50/60 Hz 230 V − 50/60 Hz
P3
115 V (±20%) − 50/60 Hz 115 V − 50/60 Hz
P3D
115 V (±20%) − 50/60 Hz
115 V DC
P4
230 V (±20%) − 50/60 Hz 24 V − 50/60 Hz
P4D
230 V (±20%) − 50/60 Hz
24 V DC
P5
115 V (±20%) − 50/60 Hz 24 V − 50/60 Hz
P5D
115 V (±20%) − 50/60 Hz
24 V DC
P6
24 V (±10%) − 50/60 Hz 24 V − 50/60 Hz
VOLTAGES AVAILABLE
P6D
24 V (±10%) − 50/60 Hz
24 V DC
ABSORBED POWER Without outlet: 2,5 VA. Outlet: 25 VA – 15 W
RELAY 250 V AC 2 A
FUSE 1 A delayed.
PULSE TIME
0,01 ÷ 9,99 sec.
PAUSE TIME
1 ÷ 999 sec.
PAUSE TIME IN AUTOMATIC
1 ÷ 999 sec.
OPERATING ∆P
0,01 ÷ 2,50 kPa
SET ALARM ∆P
0,01 ÷ 2,50 kPa
SHUT DOWN CLEANING
(N° OF CYCLES)
0 ÷ 99 cycles
REMOTE CONTROL
To be operated from a non-powered external contact (normally
open).
∆P PRECOATING 0,01 ÷ 2,50 kPa
HOUR COUNTER
0 ÷ 65,999 hours
