Assembly and Installation of –i System Test Stands Mecmesin 17
Vortex-i 0.3 N m 1.5 N m 3 N m 6 N m 10 N m
Measurement range N.m
kgf.cm
lbf.in
0-0.3
0-3
0-2.7
0-1.5
0-15
0-13
0-3
0-30
0-26
0-6
0-60
0-52
0-10
0-100
0-90
Load Measurement
Load accuracy ±0.5% of full scale
Load resolution 1:6500
Load units mN.m, N.cm, N.m, kgf.cm, gf.cm, oz.fin, lbf.ft, lbf.in
Speed
Speed range 0.1-20 rev/min (clockwise or anticlockwise)
Speed accuracy ±1% of indicated speed
Speed resolution ±0.1 rev/min
Displacement
Maximum displacement 2440 revs
Displacement accuracy 0.2º per 36,000º
Displayed resolution 0.001 revs (±0.2º)
Dimensions
Max travel of adjustable
transducer carriage
182 mm (7.2’)
Maximum headroom 505 mm (19.9’) [448 mm (17.6’)]*
Width between columns 208 mm (11.02’)
Weight 19.5 kg (43 lbs)
Capacity of lower mounting table 10-190 mm (0.39-7.5’)
Capacity of upper mounting table 10-78 mm (0.39-3.07’)
Miscellaneous
Max power requirements 100 W
Voltage 230 V AC 50 Hz or 110 V AC 60 Hz
Loadcell calibration temperature 20±2°C
* With upper and lower mounting tables fitted
