TORNADO SPECIFICATIONS
RANGE & RESOLUTION ACCURACY
±0.5% of full-scale
Calibration temperature: 20°C ± 2°C
Operating temperature: 10°C - 35°C
Temperature shift at zero load: ± 0.01% of full-scale/°C
OUTPUT
RS232-C: 8 data bits, 1 Start bit, 1 Stop bit, no parity
Digimatic (BCD) Output
Analogue: 0V at 0 load
1.5N.m, 3N.m
and 10 N.m: Approx. ±2.5V uncalibrated for
full scale clockwise/counter-clockwise
6N.m: Approx. ±1.5V uncalibrated for
full scale clockwise/counter-clockwise
PLC Signals: The output of the pin is high 5V, low 0V
Capacity (N.m) N.m N.cm mN.m
1.5
1.5 x 0.0005 150 x 0.05 1500 x 0.5
3.0
3.0 x 0.001 300 x 0.1 3000 x 1
6.0
6.0 x 0.002 600 x 0.2 6000 x 2
10
10 x 0.002 1000 x 0.2 10000 x 2
Capacity (N.m) gf.cm kgf.cm kgf.m
1.5
15296 x 5 15.296 x 0.005 N/A
3.0
30592 x 10 30.59 x 0.01 0.3059 x 0.0001
6.0
61184 x 20 61.18 x 0.02 0.6118 x 0.0002
10
101973 x 20 101.97 x 0.02 1.0197 x 0.0002
Capacity (N.m) ozf.in lbf.ft lbf.in
1.5
212.42 x 0.05 1.1064 x 0.0002 13.276 x 0.002
3.0
424.8 x 0.1 2.2127 x 0.0005 26.553 x 0.005
6.0
849.7 x 0.2 4.425 x 0.001 53.11 x 0.01
10
1416.1 x 0.5 7.376 x 0.002 88.51 x 0.02
