RS232 Commands Table: Configuration
It is possible to remotely read/configure the settings of your Tornado by sending the
following RS232 command characters:
Character in ASCII
Decimal Hexadecimal Function
M 77 0x4D Current mode
U 85 0x55 Current units
C 67 0x43 Torque sensor capacity
@ 64 0x40 Configuration status request
* 42 0x2A Continuous transmit
r 114 0x72 Normal Screen
s 115 0x73 Dual Max*
t 116 0x74 Max Clockwise*
u 117 0x75 Max Counter-clockwise*
v 118 0x76 Dual Peak Clockwise**
w 119 0x77 1st Peak Clockwise**
x 120 0x78 Dual Peak Counter-clockwise**
y 121 0x79 1st Peak Counter-clockwise**
a 97 0x61 N.m
b 98 0x62 N.cm
c 99 0x63 mN.m
d 100 0x64 gf.cm
e 101 0x65 kgf.cm
f 102 0x66 kgf.m
g 103 0x67 ozf.in
h 104 0x68 lbf.ft
i 105 0x69 lbf.in
? 63 0x3F Transmit the current reading
CTRL a 1 0x01 TXD key
CTRL b 2 0x02 UNITS key
CTRL c 3 0x03 MAX key
CTRL d 4 0x04 RESET key
CTRL e 5 0x05 ZERO key
Note: Displayed units will only change if it is applicable to the torque sensor capacity of the
Tornado.
*Only if % TAMP EV function is disabled
**Only if % TAMP EV function is enabled
