Communications Cables
Interface cables for connecting your Tornado to peripheral devices:
Allocation for the pins on the male 15 way 'D Type' Communication Connector:
Cable
Mecmesin
Part Number
Tornado to RS232 (9-pin D-type) 351-059
RS232 (9-pin D-type) to USB converter kit
432-228
Tornado to Digimatic (Mitutoyo 10-way IDC)
351-058
Tornado to Analogue 351-060
Tornado to PLC 351-063
Tornado to Footswitch 1 351-061-vo1
Tornado to Footswitch 2 351-061-vo2
Universal Expansion Module
(for connected up to 5 cables simultaneously)
432-127
Pin Out:
1 Analogue Output
2 RS232 Transmit
3 RS232 Receive
4 Digimatic Clock Output
5 Digimatic Ready Output
6 +5 volts
7 FREEZE Reading Input
8 not used
9 Footswitch 2 Input
10 Ground
11 Digimatic Request Input
12 Digimatic Data Output
13 Footswitch 1 Input
14 PLC Output
15 not used
