Figure 5.2: Exploded Upper Cabinet (M)
Speaker ( , PA 0626)Electrical
Starter-110
( , PA 0621 1)Electrical Ballast-110 ( , PA 0620 1)Electrical
Fluorescent Lamp
( , PA 0619)Electrical
Fluorescent Lamp Assembly
( , PA 0618)Electrical
I.O.Board ( , PE 0609)Electrical
ATX Power Supply
( , PE 0614)Electrical
Fan
( , PE 0612)Electrical Hand Cup ( , PA 0121)Electrical
Hook Latch Security
17" LCD Monitor ( , PE 0508)Video
LCD Rack
(Cabinet, PA 0129M)
BY MEDALIST
Power Supply Strap
