Medalist Spectrum E-Tec - Page 16

Figure 6.1: Exploded Door (T)
14
Door ( , PA 0021)Door
Light Diffuser ( , PE 0124R)Cabinet Catch Ring Section ( , PG 0221)Dart Head
Diffuser Mounting Nut ( , PA 0125)Cabinet Light Diffuser ( , PE 0124L)Cabinet
Wing Nut, Star Washer ( , PA 0219)Dart Head
Catch Ring Screw ( , PA 0222)Dart Head
Player Button-Yellow ( , PA 0627)Electrical
Select/Change Button-Red ( , PA 0628)Electrical
