15
Figure 6.2: Exploded Door (M)
Light Diffuser ( , PO 0124R)Cabinet
Light Diffuser ( , PO 0124L)Cabinet
Door ( , PE 0021 T)Door
Catch Ring Section ( , PG 0221)Dart Head
Diffuser Mounting Nut ( , PA 0125)Cabinet
Catch Ring Screw ( , PA 0222)Dart Head
Wing Nut, Star Washer ( , PA 0219)Dart Head
