Medalist Spectrum E-Tec - Page 18

16
Figure 7: Exploded Dart Head
Rubber ( , PA 0213)Dart Head
Segments: ( ,Dart Head Center Bull: PA 0203 Outer Bull: PA 0204 Pie: PA 0205, PA 0206 Triple: PA 0207, PA 0208 Block: PA 0209, PA 0210 Double: PA 0211, PA 0212 Mounting Bolt ( , PA 0231)Dart Head
Spider ( , PA 0202)Dart Head
Switch Matrix
( , PA 0214)Dart Head
Back Board ( , PA 0215)Dart Head
Knurled Nut, Star Washer ( , PA 0218)Dart Head
Target Interface Board
( , PA 0631)Electrical
