Rear Panel
This button is used to change the reverb level.
20.PAD INDICATORS
Display the pad currently being played.
21.DEMO
This button can be used to start or stop demo song playing.
22.NOTE
This button can be used to change the midi note of pad.
19.REVERB
This port is used to connect with the external audio device,like CD player or MP3 player.
24.PHONES JACK
This jack is used to connect with headphones
25.PEDAL INPUT JACKS
Kick and hi-hat pedal input jacks.
26.USB JACK
This port is used to connect with external device.
27.DC INPUT
Connect to a DC 12V.
23.AUXIN INPUT
25
24 26 2723
