Medeli DD315 User Manual

Operation
Select a Drum Kit
Set Pad Voice
Kit menu is the default menu after power on, default
valueis 001.
Press [KIT] button to enter kit menu. The 3-digit LED
will show the current kit number with the corresponding
menu indicator lit up. The button [+] / [ ] can
be used to select any kit
SELECT
(preset kit 1-45, user kit 46-50)
as the current kit.
-
Press [ ] button to enter menu. Default
value will be the voice value of the hi-hat pad based on
different kit selected. For example, if kit 001 has been
selected, then press voice, the value on LED will be
161, which is the voice value of the hi-hat pad.
If voice is selected the corresponding menu
indicator will be lit up.
In this menu, the 3-digit LED will show the voice number
of current pad, The button [+] / [ ] can be
used to select any voice(1-265, loop) for current pad.
VOICE voice
menu
-SELECT
Press [VOLUME] button to enter menu. If
menu is selected,the corresponding menu indicator will
be lit up.
In this menu, the 3-digit LED will show the volume of
current pad, which can be selected by pad hitting. The
button [+] / [-] can be used to the
volume (0-31)
voice voice
SELECT
of the current pad.
change
Set pad volume
7
Press the [PAN] button to enter menu. If
menu is selected, the corresponding menu indicator will
be lit up.
In this menu, the 3-digit LED will show the pan of current
pad, which can be selected by pad hitting. The button
[+] / [-] can be used to change the pan(-8~+8)
of the current pad.
voice voice
SELECT
Set pad pan
0
5
25
75
95
100
AW_DD315_Manual_G08_150901
2015󾾠󾾠9󾾠󾾠2󾾠󾾠 15:38:18

Medeli DD315 Specifications

General

Type	Electronic Drum Kit
Number of Pads	7
Built-in Sounds	265
Demo Songs	10
Built-in Effects	Reverb
Polyphony	32 notes
Metronome	Yes
Display	LED
Pad Features	Touch Sensitive
Connectivity	Headphone output, Aux input, MIDI output
Power Supply	6 x C batteries or DC 9V adapter
Drum Kits	45 preset, 5 user
