Making the Settings for MIDI
14
About MIDI
MIDI (Musical Instrument Digital Interface) is a standard that allows performance data and other
information to be exchanged among electronic musical instruments and computers.
MIDI Connection
MIDI OUT: This terminal transmits data from the digital drum to other MIDI devices.
Connecting with an External Sound Device
The digital drum transmission channel for the drum kit is fixed to Channel 10. It will output MIDI
data generated by the triggers when hitting the pads or stepping on the Hi-Hat control pedal (Note
ON/OFF, and Foot messages).
Song playback data and metronome notes are not transmitted.
MIDI Note Number to be Transmitted/Received by Each Pad
Each drum kit can have it's own set of MIDI note to be transmitted/received by each pad, useful for
advanced purpose.
Specifications
Drum Pad:
Voices:
Drum kits:
Song:
Controls:
Display:
Connections:
Power Supply:
4 drum pads , 3 cymbal pads ,1 hi-hat control pedal , 1 kick trigger
310 voices
24 preset kits, 11 user kits
60 preset songs
POWER SWITCH, START/STOP, SAVE, KIT, VOICE/VOLUME,
SONG/VOLUME, DRUM OFF, CLICK, HI-HAT, CRASH, RIDE,
HI-HAT CONTROL, SNARE, TOM 1, TOM 2, TOM3, KICK,
VOLUME, + / -, TEMPO + / -
LED display
MIDI OUT
Hi-hat control
Hi-hat
Crash
Ride
Snare
Tom 1
Tom 2
Tom 3
Kick
Output (R & L/MONO)
Aux in
AC adaptor ( 9V)
Trigger MIDI Note Trigger MIDI Note Trigger MIDI Note Trigger MIDI Note
Kick 36 Tom2 45 Crash 49 Hi-hat P 44
Snare 38 Tom3 43 Hi-hat O 46 Splash 21
Tom1 48 Ride 51 Hi-hat C 42
Note:
For more information on received MIDI messages, refer to MIDI implementation chart.
