The Connectors
Ensure the piano is turned
off when connecting and
disconnectiong the power.
1、
Turn the volume switch
anti-clockwise to reach
the minimum volume
level.
Connect the rear-panel AUX OUT jack to amplified
speakers, amplifiers or domestic hi-fi-units for
external amplification.
There are two headphones jacks on the left underneath
the piano body.
When an optional set of stereo headphones is connected
with the headphones jack 2, the sound from speakers
will switch off automatically resulting in only the sound
from headphone to be heard.
When jack 1 is connected with the stereo headphones,
the sound can be heard from both headphones and
speakers of the piano.
Headphones
Jack 1
Headphones
Jack 2
2、
3、
4、
If you have done the
above procedures you
are now safe to turn
on the piano.
11
Using the AC power jack
Using headphones jacks
Using the AUX OUT jack
Plug the power cable into
an AC power outlet.
1、
2、
Set to minimumTurn off
Turn on
NOTE:
When the piano is not in use or in the time of thunder-
storm, please disconnect the power for safety sake.
NOTE:
Connect both left(L) and right(R) channels for the stereo
result. If you only connect either one of the channels, the
connected channel will only take effect.
NOTE:
Never use the headphones with high volume, as it may
hurt your ears.
To prevent the damage of the speakers, ensure that the
volume is set to the minimum level before connecting
the power and other devices.
VOLUME
