Medeli DP269 User Manual

Set-up Guide
7
3.Side Panel and Pedal Box assembly
4.Rear Panel assembly
Fix the rear panel to the side panels with 2 screws and to the bottom of the rear panel with 5 screws⑦.⑧
NOTE:
Please use the screws that be supplied, do not use the other screws.
6.Screws 6X60(4pcs)
12.Plastic C aps (4pcs)
12
6
4pcs 6X60 Screws
4pcs Plastic Cap
12
6
Place t he p edal b ox o n t he t wo s ide p anel s a nd t hen u se 4pieces s crews t o f as ten t he s ide p anels a nd c over
the P lastis c aps
⑥
7.Screws 4X15 (5pcs)
8.Screws M 6X12 (2pcs)
2pcs M6X12 screws
5pcs 4X15 screws
8
8
7
