MediaShop 5 mins Shaper User Manual

1312
Part List
№ DESCRIPTION Q’TY Q’TY
1 Front main frame 1
2 Rear support tube 1
3 Slide tube 1
4 Handle bar 1
5 Foam A 2
6 Foam B 4
7 Velcro 1
8 End cap for main frame 4
9 Protect cap 2
10 Round end cap 6
11 Foam grip A 2
12 Computer 1
13 Pulley 4
14 Bearing 8
15 Pin 2
16 Axes 1
17 Upper computer wire 1
18 Bushing for wire A 1
19 Lower computer wire 1
20 Bushing for wire B 1
21 Allen bolt M8×45L 2
22 Allen bolt M8×40L 2
23 Washer 4
24 Nylon nut 8
25 Allen bolt M8×40L 4
26 Cushion A 2
27 Metal bushing A 4
28 Metal bushing B 4
29 Curve washer ID8.2×OD22.2 2
30 Big cover 1
31 Cover of handle bar 2
32 Foam grip B 2
33 Transportation wheel 2
34 Cushion B 2
35 Screw M5×12L 2
36 Allen bolt M6×50L 2
37 Nut 2
38 End cap 2
39 End cap for handle bar 2
40 Magnet 1
41 Allen key 1
42 Spring washer 2
ASSEMBLY DIAGRAM
Nr. Beschreibung Menge
01 Front main frame 1
04 Handle bar 1
05 Foam A 2
06 Foam B 4
10 Round end cap 6
12 Computer 1
15 Pin 2
17 Upper computer wire 1
Nr. Beschreibung Menge
19 Lower computer wire 1
22 Allen bolt M8×40L 2
29 Curve washer 2
30 Big cover 1
31 Cover of handle bar 1
35 Screw M15×12L 2
42 Spring washer 2
