MediaTek LinkIt™ Smart 7688 User Manual
Category Feature
LinkIt Smart 7688
Spec.
Pin numbers
• P22, P23,P24
(Shared with
on-board
flash)
• P25
Max. Speed
25 MHz
SPI Slave
Set count 1 (MT7688AN)
Pin numbers
P28, P29, P30,
P31
Max. Speed
25 MHz
I2S
Set Count
1 (MT7688AN)
Pin numbers
P10, P11, P12,
P13
I2C
Set Count
1
Pin numbers
P20, P21
Speed
120K/400K
UART (Lite)
Set Count
3 (MT7688AN)
Pin numbers
P8, P9, P16, P17,
P18, P19
Max. Speed 115,200 bps
USB Host
Pin Count
1 (MT7688AN)
Pin numbers
P6, P7
Connector type
Micro-AB
Communicatio
n
Wi-Fi
1T1R 802.11 b/g/n
(2.4G)
Ethernet
1-port 10/100 FE
PHY
Pin numbers
P2, P3, P4, P5
User Storage SD Card
Micro SD
SDXC
Table 5 LinkIt Smart 7688 development boards specifications
