Putting the Device On
!
Align Patch in center of chest and avoid shoulder fold as shown.
Take care not to insert the Pendant upside down. Be sure the slightly
curved end of the Pendant — the end at the bottom below the Power
Button — is ush against the matching beveled part of the Cradle.
Insert Battery Insert Pendant Peel Backing
Adhere to Chest Remove Tabs
Do Not Move Patch
Over to Shoulder Area
7
5
8
6 7
9
