Notebook Front View
Front View Closed Position
Right-Hand Side
Left-Hand Side
Descriptions
1
2
345
6
7
8
9
10
11
12 13 14
14a
18 19 20
21 22 23
24
15 16 17
* See the instruction manual for more information
** Ports with dual function. Conguration is set with the
included software.
1 TFT Display
2 Keyboard
3 Device Indicators
4 Integrated Touchpad Buttons
5 Touchpad
6 Palmrest
7 Webcam
8 Microphone
9 Kensington®Lock
10 Power Socket
11 External monitor port VGA
12 LAN Port (RJ-45)
13 HDMI Connector
14 USB Port 3.0
14a USB Port 3.0 with charging function for mobile
phones*
15 Loudspeaker
16 Multimedia Card Reader
17 Loudspeaker
18 Microphone**
19 Audio Out**/Digital Audio Out (S/P-DIF, optical)
20 USB Port 2.0
21 Optical Drive
22 Disc Eject Button
23 Emergency Ejection
24 Power ON/OFF
