DSD™-201 Endoscope Reprocessor Service Manual
APPENDIX
Rinse 3 Endoscope channel 30 sec 30 sec |Osec | 999 Factory Set | 84 Diag. 63
flush with water sec
Basin fill minimum 90 sec 90 sec” | 0 sec |999 Factory Set |85 Diag. 62
(level sensor not moni- sec
tored)
Basin fill balance (sen- | 5 min 10sec | 一 ーー Hard 86
sor monitored) * Coded
Top off 30 sec 30 sec |O sec | 999 Factory Set | 87 Diag. 67
sec
Re-circ | Replenish with fresh 4 min 4 min O min | 99m:59 | User Set 88 or Setup 5
water, or re-circulation s 89 Rinse 3
is active.
Drain the basin while 60 sec 60 sec |O sec | 999 Factory Set | 90 Diag. 61
flushing the scope sec
channels
Drain 30 sec 30 sec |--- 一 一 Hard 91
Coded
Air purge through 5 sec 5 sec ーー ーー Hard 92
chamber line Coded
n Re-circ | Air purge through re- 10 sec 10 sec | 一 ーー Hard 93
i circulation lines Coded
Endoscope channel air | 30 sec 30sec [0sec | 999 Factory Set | 94 Diag. 63
purge sec
. Clear air lines 5 sec 5 sec ーー ーー Hard 95
kk Coded
