20
NNUAL PM INSTRUCTIONS
PREVENTATIVE MAINTENANCE KIT
Figure 25 Figure 26
Figure 27
Each reservoir has three ports extending to the right side (when looking at the SSG from the front of the machine). Each
port has an O-ring that needs to be replaced. The part number is 43100-302, same O-ring as used on the pumps.
Remove the O-ring from the tank connection.
Coat each new O-ring with a light coat of silicone grease. Apply the new O-ring to the tank connection. See
figure 27. There are three O-rings per tank.
NOTE:Spring
andball
