38
NNUAL PM INSTRUCTIONS
PREVENTATIVE MAINTENANCE KIT
Figure 44 Figure 45
Place the Part A and Part B bottles back into the drawer.
Reinstallation of Detergent and Alcohol Bottles
Mechanical
Using a 3/8” Allen wrench, insert and tighten the four Detergent/Alcohol mounting screws into the brackets.
Electrical
Connect the red level sensor cables to the sensor harness.
Power cord should be
securely inserted
Back side
of SSG
Module
To Next Page
