Rollator Components
Figure 1
Assembled Ultra-Light Rollator
A. Hand Grips
B. Hand Brake Lock
C. Padded Seat
D. Padded Backrest
E. Triangular Hand Screw
F. 5.5” Front Wheels
G. Folding Hinge
H. 5.5” Rear Wheels
I. Brake Cable
Figure 2
Triangular Hand Screw
4
A
B
C
D
E
H
G
F
I
Figure 3
Hand Brakes
