Rear Wheel Assembly
1. Turn wheel so that it is facing outside of rollator (see Figure A).
2. Insert wheel to desired height depicted by numeric holes (see Figure B)
and use chart below for recommended height settings).
3. Insert triangular hand screw into hole on same side of wheel so that
the triangular hand screw stays outside of rollator frame.
4. Tighten triangular hand screw (Important: Hand Tighten Only!) until secure
(see Figure C).
5. Repeat steps 1-4 for other rear wheel.
Figure CFigure BFigure A
Recommended Height:
Your feet should comfortably touch the
ground when you are seated on rollator.
Height Range:
Under 5’ Hole 1 or 2
5’1”-5’6” Hole 3 or 4
5’7” and over Hole 5 or 6
Note: These are only recommended
heights, as each individual is built
differently.
7
