1. Power button
2. Home Key (Software Key)
3. Charging Port
4. Sound Hole
5. Indicator light
The Personal Diabetes Manager (PDM)
• The Glucose Sensor (MD3658 for 14 days) is inserted under the skin to measure your glucose
level in interstitial fluid.
• The Transmitter (MD1158) records Sensor data and sends data to the PDM via Bluetooth Low
Energy.
• The Sensor (with Transmitter snapped in) is waterproof at 8 feet (2.5 meters) for 60 minutes
(IP28).
• Store the Sensor at temperatures between 2°C (36°F) and 30°C (86°F).
• Store the Transmitter at temperatures between -10°C (14°F) and 55°C (131°F).
Glucose Sensor
Transmitter
5
CGM System Overview
