required to protect the user, based on an
estimate of exposure in actual operating
conditions (taking into account all stages of
the work cycle, e.g. the time when the tool is
switched o and when it is idling, in addition
to the start-up time).
DESCRIPTION
1. Top handle
2. Engine control lever
3. Wing nut
4. Bottom handle
5. Ejector opening
6. Fuel cap
7. Spark plug cap
8. Air lter cover
9. Front wheel
10. Oil ller plug
11. Chassis
12. Lever to adjust mowing height
13. Back wheel
14. Grass catcher
15. Clamp
16. Guide for starter cord
17. Starter handle
FIG. 1
ASSEMBLY
WARNING!
Always remove the cap from the spark plug,
switch o the lawn mower and wait until
all moving parts have completely stopped
before carrying out any maintenance and/or
cleaning.
TECHNICAL DATA
Displacement 127.1 cm
Output 2,0 kW
Engine speed 2900 min-¹
Catcher 45 l
Mowing width 41 cm
Mowing height 25-75 mm
Ignition TCI
Fuel tank 0.8 l
Fuel Unleaded petrol
Oil volume 0.5 l
Engine oil SAE30
Spark plug type F5RTC
Net weight 27 kg
Sound pressure level, LpA
80.5 dB(A), K=2 dB
Measured sound power level, LwA
90.7 dB(A), K=1.96 dB
Guaranteed sound power level, LwA
96 dB(A)
Vibration level
4.68 m/s² / 5.46 m/s², K=1.5 m/s²
Always wear ear protection.
The declared vibration and noise value, which
has been measured by a standardised test
method, can be used to compare dierent
tools with each other and for a preliminary
assessment of exposure. The measurement
values have been determined in accordance
with EN ISO 5395-1:2013.
WARNING!
The actual vibration and noise level when
using power tools may dier from the
specied maximum value, depending on how
the tool is used and what kind of workpiece
is processed. It is therefore necessary to
determine which safety precautions are
